Wafer Grinder

HY-WT9330 is equipped with one air-bearing grinding spindle and two air-bearing workpiece spindles. It can process various ultra-hard, brittle and hard-to-grind substrates up to 12 inches, enabling high-efficiency, damage-free and ultra-precise mirror grinding with outstanding thickness accuracy, suitable for the back thinning process of all types of chip wafers.

HY-WT9530 is fitted with 2 air-bearing spindles and 3 vacuum chuck tables for hard brittle substrates up to 8-inch. Operators only need to load cassettes manually, while the machine completes full automatic cycles including rough/fine grinding, cleaning and recovery. Post-grinding TTV≤1.5μm with excellent flatness and surface roughness, suitable for backside thinning of various semiconductor wafers.

HY-WT9730 supports wafers up to 12-inch. Equipped with 3 grinding air-bearing spindles and 4 workpiece air-bearing spindles, it integrates rough grinding, fine grinding and polishing processes. The full robotic workflow automatically completes wafer transfer, processing, cleaning and unloading; only manual cassette feeding is needed. Ultra-precise Z-axis feed delivers superior wafer flatness and damage-free mirror polishing, while its sturdy frame guarantees stable mass production.

HY-WT9230 is developed for ultra-hard brittle semiconductor materials up to 12 inches. Built with dual air-bearing spindles and a high-precision grinding Z-axis, it supports fully automatic mirror thinning with high efficiency and damage-free processing. Equipped with a porous vacuum chuck and ultra-fine feed control, the machine ensures superior flatness and thickness uniformity for semiconductor wafer thinning processes.

HY-IS1000 is dual-station SiC ingot laser slicing and grinding equipment combining laser modification and wafer delamination processes. It uses ultra-short pulse laser to form internal modified layers inside SiC ingots for saw-mark-free wafer splitting, delivering high throughput with ground wafer TTV ≤1.1 μm. It is essential mass-production equipment for third-generation semiconductor substrate manufacturing.

HY-WC615 double-side wafer chamfering machine is equipped with CCD vision positioning & online thickness measurement modules, self-developed core mechanical components and full auto loading/unloading system, delivering outstanding machining precision and user-friendly touch operation for wafer chamfer processing.

The HY-ST3005 handles 4–12 inch hard brittle semiconductor substrates for high-precision back thinning. Iteratively upgraded for superior accuracy and long-term stability, it features premium core assemblies (hydrostatic air-bearing grinding spindle, high-precision wafer spindle, high-rigidity large-diameter rotary table) and high automation for mass production of silicon and compound semiconductor wafers.

The HY-ST3002 handles 4–12 inch wafers for precision thinning and grinding of hard brittle semiconductors. Fully upgraded with mature processes, it features enhanced accuracy and stable long-run performance, with refined automatic thinning architecture and premium key parts: hydrostatic air-bearing grinding spindle, hydrostatic air-bearing wafer holding spindle, high-rigidity large-diameter rotary table.
